Maximum allowable peripheral load 5mm pitch: 10mm wide belt = 330 N, 16 mm wide belt = 570 N Maximum allowable peripheral load 2.5mm pitch: 6mm wide belt = 65 N Temperature range for the belts: -30✬ to +80✬ Features and options for our timing pulleysĢ.5 mm pitch available with bores sizes 3, 4, 6 and 8 mm as standardĥ mm pitch available with bores sizes 4, 6 and 8 mm as standardįeatures and options for our timing belts High tensile stainless steel reinforced polyurethane belts with widths of 6 mm, 10 mm and 16 mm, coupled with aluminium alloy machine cut pulleys, provide cost effective motion over extended centres. Spatial conditions are to some extent very narrow - meanwhile there is a belt for almost every requirement and of course the corresponding pulley profile.Reliance timing belts and timing pulleys are available in 2.5 mm and 5 mm pitch. Ever greater power levels have to be transmitted as quietly as possible. The stringent requirements of a wide range of drive systems have be taken into consideration. high power transmission due to the positive gearingĪ great deal of research was required to achieve the variety of timing or toothed belt drives that exist today. Manufacturer of Timing Belt for Automobile Industry - Timing Belt Pulleys, Industrial Timing Pulleys offered by A.This taper system is used more and more frequently because there is no need to bore and ream a groove directly into the pulley. We supply timing belt pulleys either pre-bored or with a clamping bush system such as Taper-Lock®. The self tracking HOT Helical Offset Tooth design of Conti® SilentSync eliminates the need for pulley flanges. In a timing belt drive at least one of two timing belt pulleys need two flanged wheels.

Flanged pulleys prevent the timing belts from slipping off. Smaller timing belt pulleys are supplied from the factory with flanged pulleys. The version depends on the manufacturer and may vary.

#TIMING BELTS AND PULLEYS SERIAL#

For difficult drive problems and serial applications, we recommend that you contact us for advice!įurther information about our timing belt pulleys:ĭepending on the operating conditions and gear load, timing belt pulleys can be made of grey cast iron, steel or aluminium alloys. The teeth of the belts must fit into the tooth gaps of the corresponding profile pulley without friction. It is extremely important to match the pitch of the pulley and the belt in timing belt drives. Please note that clamping bushes must always be ordered separately! POSITIVE DRIVE No slippage between Belt and Pulley means low Belt tension and small Bearing loads. Taper system timing belt pulleys for POLY CHAIN® GT or SYNCHROCHAIN® CTD belts Timing Pulleys KEY FEATURES: SYNCHRONOUS Positive tooth engagement with little backlash ensures the drive has a constant velocity ratio and a permanent relative position of Belts and Pulleys. Profile 8M-30 (also with customised number of teeth).Profile 8M-20 (also with customised number of teeth).Profiles of our taper system timing belt pulleys: Profile HOT 14 with 28 – 60 teeth, for belt width 35mm, 52,5 mm, 70 mm, 105 mm.Profile HOT 8 with 18 – 75 teeth, for belt width 16 mm, 32 mm, 64 mm.HOT standard timing belt pulleys (Helical Offset tooth) Profile AT 10 (pitch 10 mm) for belt width 50 mm.Profile AT 10 (pitch 10 mm) for belt width 32 mm.
